YOUDA COMPOSITE1.95–2.06g/cm³
Typical density
Product Images & Video
Lightweight carbon fiber with premium woven depth.
Technical Overview
Carbon fiber sheetsPremium Carbon Fiber for Lightweight Handles.
Carbon fiber handle material is a high-performance composite manufactured from carbon fiber reinforcement combined with a thermosetting epoxy resin system. It offers an excellent strength-to-weight ratio, high rigidity, low moisture absorption and a distinctive premium appearance.
Excellent strength-to-weight ratioLightweight, rigid and dimensionally stableAvailable in woven, forged and hybrid patterns
105–120M
TYPICAL ROCKWELL HARDNESS
1–30mm
Common Thickness Range
500–900MPa
Typical Flexural Strength
PropertyTypical specification
Material ConstructionCarbon fiber reinforcement combined with a thermosetting epoxy resin matrix
Material TypesWoven carbon fiber, forged carbon fiber, chopped carbon fiber and hybrid composite laminate
Weave Options3K twill weave, plain weave, unidirectional layers, forged pattern and custom decorative layups
Pattern OptionsClassic black weave, forged carbon, marbled carbon, colored carbon, metallic hybrid and custom layered patterns
Available ColorsBlack, silver, blue, red, gold, copper, green and custom hybrid color combinations
The above values are typical reference data and may vary depending on fiber orientation, resin system, laminate structure, thickness and test method. Please contact us for confirmed specifications and test reports.
Product Data
Technical and supply information.
MaterialCarbon fiber reinforced resin composite.
Supply formsSheets, knife scales, decorative panels and machined parts.
Surface optionsWoven patterns, matte or polished appearance, depending on grade.
ApplicationsPremium knife handles, tools, outdoor products and lightweight components.
Customization
Build the product around your project.
Custom dimensions
Sheet size, scale size, thickness and cut blanks.
Color and texture
Choose available colors, layers, weaves and surface appearance.
CNC machining
Contours, holes, slots, chamfers and finished parts based on drawings.
Packing and labels
Paired packing, neutral labels, custom labels and export protection.
FAQ
Common questions about this material.
Can carbon fiber be cut to custom shapes?+
Yes. CNC cutting, drilling and contour machining can be reviewed from drawings.
Can I choose the weave appearance?+
Available weave and surface options depend on the product series. Send a reference image or required pattern.
Do you offer polished finished parts?+
Finishing options can be discussed according to geometry, surface requirement and order quantity.
Request a Quote
Send dimensions, quantity and application details.
A drawing, reference image or target specification will help us confirm the right product and process.
